AXOS E3-2 Intelligent PON Node
The AXOS® E3-2 eliminates deployment complexities and simplifies your business with this multi-faceted FTTH network expansion solution
Connect customers even in the most unforgiving places
The E3-2 has a 'deploy anywhere' design that can be mounted aerially, in a pedestal, on a wall or on a pole. This flexibility reduces costs while accelerating construction and service activation - making it an ideal choice for challenging environments.
The Calix E3-2 delivers scaleability, resiliency, and efficiency to your network
- Rural communities
- Cable operators
Introducing self-diagnosis capability
Helps rural Service Providers simplify operations
Introducing a smart self-diagnostic capability on the E3-2 that makes system troubleshooting and rolling service trucks out to remote areas a thing of the past.
Software Defined Access
For cable operators seeking a simple path to SDA
The innovative Calix AXOS DPx solution on the E3-2 will dramatically reduce your operational costs and network complexity. AXOS DPx is the industry’s first virtualized DOCSIS microservice connector for seamless integration, management and control of anyPHY™ into a cable operator’s back office system.
Aggregate the access network with the E3-2 Intelligent EDGE System
The AXOS E3-2 is ideally suited for virtualized functions and facilitates a seamless transformation to software defined access.
The E3-2 simplifies the upgrade path from Gigabit to multi-Gigabit PON with field replaceable modules. Upgrade without impacting neighboring services.
Seamlessly integrate into networks by leveraging existing right-of-ways and power, without worrying about land acquisition and permitting delays.
E3-2 Intelligent PON Node
The Calix E3-2 Intelligent PON Node is a flexible and upgradable system that can be deployed cost effectively in environmentally challenged remote locations to provide PON services. Each E3-2 provides two pluggable subscriber interface modules supporting XGS-PON, GPON, and Multi-PON optics.
E3-2 features and capabilities
- Sealed remote OLT requiring no active cooling
- Pluggable module design
- Multiple powering options
- Supports XGS-PON, GPON, or Multi-PON SFP+ optics
- Configurable upstream encryption using MACsec*
- Integrated fiber management including splice tray
- Interoperability with Calix ONTs
- DOCSIS® provisioning support using DPx
- Software Defined Access enabled by the Network Innovation Platform (AXOS)
|PON module capacity
|PON ports (GPON/XGS-PON/MPM)
|4 per module (8 per E3-2)
|Network uplink ports
|4x 10GE/25GE SFP28
2x 100GE QSFP28
|Power consumption (max)
|Power supply options
|60VAC / 90VAC coax, -48VDC, commercial AC, ±190VDC span power
|-40° C to +65° C (-40° F to +149° F)
|5 to 95 percent (non- condensing)
|Physical dimensions (WxHxD)
|11.5in x 9.65in x 22in (29.2cm x 24.5cm x 55.9cm)
|Download Datasheet (login required)
